Compatible case size	Other
Outline drawing	55Wx28Hx133D
Weight	0.18 kg typ
Input Voltage	AC	85-264V
Efficiency	AC	77% typical at AC 100V/76% typical at AC 240V
Power factor
Input changeover system	Worldwide
Safety	UL60950-1, CSA60950-1
High frequency current regulation
EMI standard (Input feedback noise)	VCCI-B FCC-B CISPR22-B EN55022-B compliant
CE marking
EMS immunity	Electrostatic discharge: EN61000-4-2 compliant Radiated, radio frequency electromagnetic fields: EN61000-4-3 compliant Fast transient burst: EN61000-4-4 compliant Lightning surge: EN61000-4-5 compliant Conductive radio frequency electromagnetic fields: EN61000-4-6 compliant Power source frequency magnetic immunity: EN61000-4-8 compliant Voltage dips/regulations: EN61000-4-11 compliant
MTBF	250,000H
Operating temperature	-10 to 60 deg C.
Leakage current	0.5mA max. at AC 100V/1mA max. at AC 240V
Cooling systems	Air-cooling without blower
Insulation	AC1500V/min between AC input and FG/DC output 50 ohm min between AC input and DC output/FG and between DC output and FG
Output ground connection	Capacitor ground
Warranty	Three years after delivery; the defective unit shall be repaired or replaced at our cost if defects belong to us.

WH-C04VH-800	Output harness for OZ-030/060/FZP-040 series
WH-C05VH-800	Input Harness
WH-C05VH-800-01	Input Harness (Ferrite Core equipped)
